Milk & whey concentration systems

pumps on skid and automatic osmosis high concentration serum, flow rate 15000 lt/h

whey nanofiltration system, flow rate 10000 lt/h

Reverse Osmosis system for whey concentration, flow rate 7000 lt/h - Quebec (Canada)

skid pumps automation and reverse osmosis membrane skid with permeate polisher, flow rate 15000 lt/h

Reverse Osmosis system for serum concentration, flow rate 9000 lt/h

system for serum concentration, flow rate 4000 lt/h

switchboard/automation and inverter pumps for serum concentration system

Polishing Reverse Osmosis permeate system, flow rate 15000 lt/h

Reverse Osmosis loop and polishing machine, pumps with UL washing motors, flow rate 15000 lt/h

Reverse Osmosis system for whey concentration - detail: permeate and concentrate

PLANTS FOR WHEY CONCENTRATION

About the concentration of whey and "scotta", TECN.A creates and builds two types of membrane systems:

• Reverse Osmosis systems
• Nanofiltration systems

REVERSE OSMOSIS removes water from the whey, concentrating it up to 3 times the initial volume: this provides huge savings both in the transport of the whey and in the evaporation processes for its pulverization.

NANOFILTRATION, on the other hand, removes the water and the monovalent salts from the whey (sodium and potassium chlorides), and a part of the calcium and magnesium salts, thus realizing the whey concentration and the partial demineralisation of the same.

This technology allows to achieve higher concentration values than the osmosis (4 times), producing a concentrate with low salinity and higher protein value.

The permeate product can be discharged directly into the treatment plant or reused as it is. If, on the other hand, a higher degree of purity is required for its recycling, it will have to be reprocessed with a further stage of "POLISHER" REVERSE OSMOSIS.

USING THE CONCENTRATED WHEY IN ZOOTECHNY

In livestock farming, in the breeding of white-fleshed calves, the use of concentrated whey produced with Tecn.A.'s membrane systems (whether osmosis or nanofiltration), guarantees safe and considerable economic advantages to farmers.
